Looking for a large quantity of E-2176M? Call us at (800) 821-3354 or Request a Quote below and one of our sales representative will get in touch with you very soon.
| Model | |
| Manufacturer | Intel |
| Manufacturer Part # | E-2176M |
| Processor - Essentials | |
| Brand | Intel |
| Part No. | E-2176M |
| Processor Type | Mobile |
| Series | Xeon Processor |
| Core Model Type/ProcNo. | E-2176M |
| Processor Code Name | Coffee Lake |
| Core Stepping | U0 |
| Manufacturing Technology | 14 nm |
| Performance | |
| # of Cores | 6 |
| # of Threads | 12 |
| Clock Speed | 2.70 GHz |
| Max Turbo Frequency | 4.40 GHz |
| L3 Cache Size | 12 MB |
| Front Side Bus / QuickPath Interconnect | 8.00 GT/s |
| Thermal Power | 45 Watts |
| Processor - Memory Specifications | |
| Max Memory Size | 64 GB |
| Memory Types | DDR4-2666 |
| Memory Channels | 2 |
| ECC Memory Supported | Yes |
| Processor - Package | |
| CPU Socket Type | BGA1440 |
| Max CPU Configuration | 1 |
| TJUNCTION | 100 °C |
| Package Size | 42mm x 28mm |
| Processor - Graphics | |
| Processor Graphics | Intel UHD Graphics P630 |
| Graphics Base Frequency | 350 MHz |
| Graphics Max Dynamic Frequency | 1.20 GHz |
| Graphics Video Max Memory | 64 GB |
| Graphics Output | eDP/DP/HDMI/DVI |
| 4K Support | Yes, at 60Hz |
| Max Resolution (HDMI 1.4) | 4096 x 2304 @ 60Hz |
| Max Resolution (HDMI) | 4096 x 2304 @ 30Hz |
| Max Resolution (eDP - Integrated Flat Panel) | 4096 x 2304 @ 30Hz |
| DirectX Support | 12.1 |
| OpenGL Support | 4.5 |
| Intel Quick Sync Video | Yes |
| Intel InTru 3D Technology | Yes |
| Intel Clear Video HD Technology | Yes |
| Intel Clear Video Technology | Yes |
| # of Displays Supported | 3 |
| Device ID | 0x3E9B |
| Processor - Supplemental Information | |
| Embedded Options Available | No |
| Processor - Expansion Options | |
| Scalability | 3.0 |
| PCI Express Configurations |
1 x16 1x8+2x4 |
| Max # of PCI Express Lanes | 16 |
| Processor - Advanced Technologies | |
| Advanced Technologies |
Enhanced Intel SpeedStep Technology Idle States Instruction Set 64-bit Intel 64 Intel Hyper-Threading Technology Intel Optane Memory Supported Intel Speed Shift Technology Intel Turbo Boost Max Technology 3.0 Intel Turbo Boost Technology 2.0 Intel Virtualization Technology (VT-x) Intel Virtualization Technology for Directed I/O (VT-d) Intel VT-x with Extended Page Tables (EPT) Thermal Monitoring Technologies |
| Processor - Security | |
| Security & Reliability |
Execute Disable Bit Intel AES New Instructions Intel Boot Guard Intel OS Guard Intel Software Guard Extensions (Intel SGX) Mode-based Execute Control (MBE) |
| Warranty | |
| Product Condition | OEM |
| Standard Warranty | 21 days |
Please call at (800) 821-3354 and one of our representative will be happy to assist you with part no E-2176M. Or Request a Quote below:
