Processor - Package Model: i5-7300U Socket Type: BGA 1356 | |
Processor Type | Mobile |
Series | Core i5 Mobile |
Core Model Type/ProcNo. | i5-7300U |
Processor Code Name | Kaby Lake-U |
Core Stepping | H0 |
Manufacturing Technology | 14 nm |
# of Cores | 2 |
# of Threads | 4 |
Clock Speed | 2.60 GHz |
L3 Cache Size | 3 MB |
Front Side Bus / QuickPath Interconnect | 4.00 GT/s |
Thermal Power | 15 Watts |
Max Memory Size | 32 |
Memory Types |
DDR3L-1600 DDR4-2133 LPDDR3-1866 |
Memory Channels | 2 |
Maximum Memory Bandwidth | 34.1 GB/s |
ECC Memory Supported | No |
CPU Socket Type | BGA 1356 |
Max CPU Configuration | 1 |
TJUNCTION | 100 °C |
Package Size | 42mm X 24mm |
Processor Graphics | Intel HD Graphics 620 |
Graphics Base Frequency | 300 MHz |
Graphics Max Dynamic Frequency | 1.10 GHz |
Graphics Video Max Memory | 32 GB |
Graphics Output | eDP/DP/HDMI/DVI |
4K Support | Yes, at 60Hz |
Max Resolution (HDMI 1.4) | 4096 x 2304 @ 24Hz |
Max Resolution (HDMI) | 4096 x 2304 @ 60Hz |
Max Resolution (eDP - Integrated Flat Panel) | 4096 x 2304 @ 60Hz |
DirectX Support | 12 |
OpenGL Support | 4.5 |
Intel Quick Sync Video | Yes |
Intel InTru 3D Technology | Yes |
Intel Clear Video HD Technology | Yes |
Intel Clear Video Technology | Yes |
# of Displays Supported | 3 |
Device ID | 0x5916 |
Embedded Options Available | Yes |
PCI Express | 3.0 |
PCI Express Configurations | 1 x4 |
Max # of PCI Express Lanes | 12 |
Advanced Technologies |
Enhanced Intel SpeedStep Technology Idle States Instruction Set 64-bit Intel 64 Intel Fast Memory Access Intel Flex Memory Access Intel Hyper-Threading Technology Intel My WiFi Technology Intel Optane Memory Supported Intel Speed Shift Technology Intel Turbo Boost Technology 2.0 Intel Virtualization Technology (VT-x) Intel Virtualization Technology for Directed I/O (VT-d) Thermal Monitoring Technologies |
Instruction Set Extensions | Intel SSE4.1, Intel SSE4.2, Intel AVX2 |
Security & Reliability |
Execute Disable Bit Intel AES New Instructions Intel Boot Guard Intel Memory Protection Extensions (Intel MPX) Intel OS Guard Intel Software Guard Extensions (Intel SGX) Intel Trusted Execution Technology |
