GAMA770T-UD3 Gigabyte Socket AM3 AMD 770/ SB710 Chipset AMD Phenom II/ AMD Athlon II Processors Support DDR3 4x DIMM 6x SATA 3.0Gb/s ATX Motherboard (Refurbished)

Mfg Part No:

GAMA770T-UD3

Call us at (800) 821-3354 for price and availability or Request a Quote below and one of our sales representative will get in touch with you very soon.

Technical Specifications for GAMA770T-UD3

Model
Manufacturer Gigabyte Tech
Manufacturer Part # GAMA770T-UD3
Performance
Product Type System Board
Form Factor ATX
CPU Socket Type Socket AM3
Supported CPU(s) AMD Athlon II Processor
AMD Phenom II Processor
Chipset AMD 770
South Bridge Chipset AMD SB710
Number of Memory Slot(s) 4
Number of Memory Channel(s) 2
Supported Memory Standard(s) PC3-10600 (DDR3-1333)
PC3-12800 (DDR3-1600)
PC3-8500 (DDR3-1066)
Maximum Installed Memory 16 GB
Expansion Slots PCI-E 2.0 x16
Expansion Slots Details 1 x PCI Express x16 slot, running at x16 (The PCI Express x16 slot conforms to PCI Express 2.0 standard.)
4 x PCI Express x1 slots
2 x PCI slots <>/ol0
Storage Controller SATA 3.0 Gbps
Audio Controller Realtek ALC888
Network Gigabit Ethernet
Connectors/Ports 24-pin ATX Power Connector
8-pin 12V Power Connector
Chassis Fan Connector
CPU Fan Connector
RJ-45
Serial
USB 1.1
USB 2.0
Connectors/Ports Details Internal I/O Connectors
  • 1 x 24-pin ATX main power connector
  • 1 x 8-pin ATX 12V power connector
  • 1 x floppy disk drive connector
  • 1 x IDE connector
  • 6 x SATA 3Gb/s connectors
  • 1 x CPU fan header
  • 2 x system fan headers
  • 1 x power fan header
  • 1 x front panel header
  • 1 x front panel audio header
  • 1 x CD In connector
  • 1 x S/PDIF In header
  • 1 x S/PDIF Out header
  • 2 x USB 2.0/1.1 headers
  • 1 x IEEE 1394a header
  • 1 x parallel port header
  • 1 x serial port header
  • 1 x power LED header
  • 1 x chassis intrusion header

  • Back Panel Connectors
  • 1 x PS/2 keyboard port
  • 1 x PS/2 mouse port
  • 1 x coaxial S/PDIF Out connector
  • 1 x optical S/PDIF Out connector
  • 8 x USB 2.0/1.1 ports
  • 2 x IEEE 1394a ports
  • 1 x RJ-45 port
  • 6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone)
  • Request for Quote:  GAMA770T-UD3

    Please call at (800) 821-3354 and one of our representative will be happy to assist you with part no GAMA770T-UD3. Or Request a Quote below:



    General Information

  • GAMA770T-UD3 Gigabyte Socket AM3 AMD 770/ SB710 Chipset AMD Phenom II/ AMD Athlon II Processors Support DDR3 4x DIMM 6x SATA 3.0Gb/s ATX Motherboard (Refurbished)
