P6T7-WS-BO-R ASUS P6T7 WS Socket LGA 1366 Intel Xeon / Core i7/ Core i7 Extreme Edition Processors Support DDR3 6x DIMM 2x SATA 3.0Gb/s / 6x SATA 3.0Gb/s CEB Motherboard (Refurbished)

Mfg Part No:

P6T7-WS-BO-R

Global Part Number (GPN):

1465398381

$426.77 $948.39 You Save: $521.62 (55% Spring Discount)

Availability:In Stock

Order with Confidence

Need to confirm compatibility or quantity? Our team is here to help.

1-800-821-3354 | [email protected] | Live Chat

Supporting IT Teams Since 1986

Quantity

Looking for a large quantity of P6T7-WS-BO-R? Call us at (800) 821-3354 or Request a Quote below and one of our sales representative will get in touch with you very soon.

Technical Specifications for P6T7-WS-BO-R

Model
Manufacturer	ASUS
Manufacturer Part #	P6T7-WS-BO-R
Performance
Product Type	System Board
Form Factor	SSI CEB
CPU Socket Type	LGA 1366
Supported CPU(s)	Intel Core i7 Processor
Supported CPU Technologies	Hyper-Threading Technology Intel Turbo Boost Technology Intel Virtualization Technology
Chipset	Intel X58 Express
South Bridge Chipset	Intel ICH10R
Number of Memory Slot(s)	6
Number of Memory Channel(s)	3
Supported Memory Standard(s)	PC3-10600 (DDR3-1333) PC3-14900 (DDR3-1866) PC3-16000 (DDR3-2000) PC3-8500 (DDR3-1066)
Maximum Installed Memory	24GB
Expansion Slots	PCI-E 2.0 x16
Expansion Slots Details	1 x PCIe 2.0 x16 6 x PCIe 2.0 x16 (triple x16 or six x8)
Storage Controller	SATA 3.0 Gbps SATA 6.0 Gbps
Storage Controller Details	Support Raid 0, 1 Marvell 88SE6121 controller 2 x eSATA 3Gb/s port(s), red black, 2 x SAS 3Gb/s port(s) Marvell 88SE6320 controller Intel ICH10R controller Support Raid 10, 0, 1, 5 navy blue, 6 x SATA 3Gb/s port(s)
Audio Controller	Analog Devices AD2000B
Network	Gigabit Ethernet
Connectors/Ports	8-pin 12V Power Connector Chassis Fan Connector CPU Fan Connector PS/2 PS/2 Keyboard PS/2 Mouse RJ-45 TPM Header USB 2.0
Connectors/Ports Details	Internal I/O Connectors 1 x CPU Fan connector(s) 3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s) 1 x System panel(s) 1 x TPM connector(s) 1 x 8-pin ATX 12V Power connector(s) 3 x Chassis Fan connector(s) 1 x Chassis Intrusion connector(s) 1 x IEEE 1394a connector(s) 1 x CD audio in(s) 1 x Power Fan connector(s) 1 x Front panel connector(s) 1 x 24-pin EATX Power connector(s) 1 x S/PDIF out header(s) Back I/O Ports 2 x LAN (RJ45) port(s) 6 x USB 2.0 2 x eSATA 3Gb/s 6 x Audio jack(s) 1 x Coaxial S/PDIF out 1 x Optical S/PDIF out 1 x PS/2 keyboard/mouse combo port(s)
Other Information
Features	ASUS Exclusive Features AI Nap Express Gate ASUS Q-Design ASUS Q-Connector ASUS EZ DIY ASUS O.C. Profile ASUS CrashFree BIOS 3 ASUS Quiet Thermal Solution Stack Cool 2 ASUS Fan Xpert
