Model | |
Manufacturer | ASUS |
Manufacturer Part # | M5A78L-M |
Performance | |
Product Type | System Board |
Form Factor | Micro ATX |
CPU Socket Type | Socket AM3+ |
Supported CPU(s) |
AMD Athlon II Processor AMD Phenom II Processor AMD Sempron Processor |
Supported CPU Technologies | Cool n Quiet Technology |
Chipset | AMD 760G |
South Bridge Chipset | AMD SB710 |
Number of Memory Slot(s) | 2 |
Number of Memory Channel(s) | 2 |
Supported Memory Standard(s) |
PC3-10600 (DDR3-1333) PC3-12800 (DDR3-1600) PC3-14900 (DDR3-1866) PC3-8500 (DDR3-1066) |
Maximum Installed Memory | 16 GB |
Expansion Slots |
PCI PCI-E 2.0 x1 PCI-E 2.0 x16 |
Expansion Slots Details | 1 x PCIe 2.0 x16 1 x PCIe 2.0 x1 1 x PCI |
Storage Controller | SATA 3.0 Gbps |
Audio Controller | Realtek ALC887 |
Network | Gigabit Ethernet |
Connectors/Ports |
Audio-In Audio-Out Chassis Fan Connector COM CPU Fan Connector D-Sub PS/2 Keyboard PS/2 Mouse RJ-45 USB 2.0 |
Connectors/Ports Details | Back I/O Ports
Internal I/O Ports |
